Champions in the textile industry

At Habasit we have been setting the benchmark for spindle tapes for decades, and today our products are used in the textile industry worldide. Drawing on our extensive range, you can find the most suitable spindle tape for your specific application, no matter how demanding.

Visit our Product Portal

Portfolio overview

Our polyamide and polyester spindle tapes offer a long service life and cost savings. By preventing fiber accumulation, cleaning is no longer necessary and production is uninterrupted. Moreover, Habasit tapes provide constant spindle speed and uniform yarn quality.

Our polyamide and polyester spindle tapes offer a long service life and cost savings. By preventing fiber accumulation, cleaning is no longer necessary and production is uninterrupted. Moreover, Habasit tapes provide constant spindle speed and uniform yarn quality.

Polyamide spindle tapes

Polyamide spindle tapes are built with a durable polyamide traction layer. They deliver reliable power transmission from the machine's drive system to consistent yarn quality. As high-performance driving tapes for the textile industr, they are widely used in ring spinning and twisting machines.

Main features:

  • Constant spindle speed and yarn quality
  • Robust and reliable
  • High abrasion resistance of belt surfaces
  • Long service life
  • Good price/value ratio
  • No fiber accumulation, no cleaning

Applications:

  • Ideal for ring spinning machines, twisting machines, and high-speed textile processes requiring precise and dependable spindle drive

Key products:

Product Code Key feature 1 Key feature 2
TS-5 high abrasion resistance dimensional stability
TS-10 constant CoF high reliability
HS-5G good price/value ratio robust

Polyester spindle tapes

Polyester spindle tapes are high-performance driving belts used primarily in the ring spinning machines. Their job is to transfer power from the driving system to the spindles, ensuring consistent spindle speed and uniform yarn quality. The tapes can handle spindle speeds over 24,000 rpm, with no fiber fly accumulation, and a long and reliable service life. They are an alternative to polyamide spindle tapes and are valued fot their energy efficiency, long service life, and stable performance at high spindle speeds. As saving energy becomes increasingly important due to high-speed operations in textile, Habasit offers the highly efficient Habasit polyester W-8 and C-8 spindle tapes that saves 5 to 8% energy and costs saves up to 8% of ring frame motor energy consumption, leading to savings of up to 1 USD per spindle and year.

Main features:

  • Constant spindle speed and yarn quality
  • No fiber accumulation, no cleaning
  • Minimized speed loss during spindle stop
  • Fast running-up time after spindle stop
  • High abrasion resistance of belt surfaces
  • Low energy consumption
  • Long service life
  • Simple and fast to join (adhesive-free Flexproof method)

Applications:

  • It is particularly suitable as a driving belt for medium- and high-end spinning machines with spindle speeds above 18,000 rpm

Key products:

Product Code Key feature 1 Key feature 2
W-8 high belt flexibility energy efficient
C-8 constant high CoF dimensionally stable
